On the other hand, it is volumetric because every point within the 3D texture coordinate space corresponds to the face of the cube it comes closest to:Ĭonverting an equirectangular image into a cubemap is most commonly used for some navigable virtual environment solutions or when editing the north and south poles of spherical panoramas.Įquirectangular images are stretched in the 'latitude' direction. On one hand, a cubemap is a kind of surface texture, like an ordinary 2D texture. When folded, the view is remapped to the faces of a cube which fit seamlessly. The six images are typically arranged as an unfolded cube (‘horizontal cross’).Įach of the cubemap faces has an appropriate texture map. These maps are often created by imaging the scene with six 90-degree FoV cameras giving a left, front, right, back, top, and bottom texture.
The cubic format/cubemap uses six cube faces to fill the whole sphere around the viewer. (Images with a single spherically distorted texture can be instantly tested here. Such images can be captured with a 360-degree camera or using “cheap and dirty” methods like this. This format has become popular in social media and marketing and has found application in 3D graphics programs, simulations of interiors, immersive panoramic movies, and computer and video games.Īn equirectangular panorama consists of a single rectangular image whose width and height correlate as 2:1. They contain light data originating from all directions, and therefore can be visualized as comprising the points on a sphere. Unlike cylindrical views, spherical panoramas incorporate a 180° vertical viewing angle and a 360° horizontal viewing angle. This means that the top and bottom of the imaginary cylinder will be missing in such map images when they are ‘wrapped.’ For example, cylindrical projections convey the scene visible in all directions, except for right above the viewer’s head and under their feet.
#Panorama video convert to 6 face full
Panoramic projections are used to map a full or partial 3D scene onto a 2-dimensional surface.
We would like to share some tips and tricks for solving typical problems while projecting a panorama onto a cube.Įquirectangular Panorama and Cubic Format In this post, we are primarily referring to two main spherical image formats: equirectangular panorama and cubemap. For realistic surroundings and convincing real-time effects in games, developers and designers use map textures that convey a very wide or entire view of a scene.
